Description
Overview:
- AC & DC V
- AC & DC A
- Resistance
- Capacitance
- Temperature
- Frequency and duty ratio
- Diode
- Continuity
Features:
- 6000 count
- True RMS
- NCV
- Flashlight
- Data hold and auto power off
- Low battery indication
171TRMS+
Original price was: ₹3,780.00.₹2,800.00Current price is: ₹2,800.00.
| Model | Metrix+ 171TRMS+ | |||
| Safety standard | GB/T 13978-92, IEC 61010-1, IEC 61010-2-032, CAT III 1000V CAT IV 600V | |||
| DC Voltage | Range | Resolution | Accuracy | |
| 600mV | 0.1mV | +(0.5% + 3) | ||
| 6V | 1mV | +(0.5% + 3) | ||
| 60V | 10mV | +(0.5% + 3) | ||
| 600V | 100mV | +(0.5% + 3) | ||
| 1000V | 1V | +(0.8% + 5) | ||
| AC Voltage(True RMS) | Range | Resolution | Accuracy | |
| 6V | 1mV | +(0.8% + 3) | ||
| 60V | 10mV | +(0.8% + 3) | ||
| 600V | 100mV | +(1% + 10) | ||
| 750V | 1V | +(1% + 10) | ||
| DC Current | Range | Resolution | Accuracy | |
| 60mA | 10uA | +(1% + 3) | ||
| 600mA | 100uA | +(1% + 3) | ||
| 20A | 10mA | +(1.5% + 3) | ||
| AC Current (True RMS) | Range | Resolution | Accuracy | |
| 6uA | 10nA | +(0.8% + 3) | ||
| 60mA | 10uA | +(0.8% + 3) | ||
| 600mA | 100uA | +(0.8% + 3) | ||
| 20A | 10mA | +(1.2% + 3) | ||
| Resistance | Range | Resolution | Accuracy | |
| 600? | 0.1? | +(0.8% + 3) | ||
| 6K? | 1? | +(0.8% + 3) | ||
| 60K? | 10? | +(0.8% + 3) | ||
| 600K? | 100? | +(0.8% + 3) | ||
| 6M? | 1K? | +(1.2% + 3) | ||
| 60M? | 10K? | +(1.2% + 3) | ||
| Capacitance | Range | Resolution | Accuracy | |
| 9.999nF | 1pF | +(4% + 3) | ||
| 99.99nF | 10pF | +(4% + 3) | ||
| 999.9nF | 100pF | +(4% + 3) | ||
| 9.999uF | 1nF | +(4% + 3) | ||
| 99.99uF | 10nF | +(4% + 3) | ||
| 999.9uF | 100nF | +(4% + 3) | ||
| 9.999mF | 1uF | +(5% + 3) | ||
| 99.99mF | 10uF | +(5% + 3) | ||
| Temperature | Range | Resolution | Accuracy | |
| -20 ~ 300C | 1C | +(1% + 4) | ||
| 301 ~ 1000C | 1C | +(1.9% + 5) | ||
| -4F ~ 600F | 1F | +(1.2% + 6) | ||
| 601F ~ 1832F | 1F | +(1.9% + 6) | ||
| Frequency | Range | Resolution | Accuracy | |
| 9.999Hz | 1mHz | +(1% + 3) | ||
| 99.99Hz | 10mHz | +(1% + 3) | ||
| 999.9Hz | 100mHz | +(1% + 3) | ||
| 9.999kHz | 1Hz | +(1% + 3) | ||
| 99.99kHz | 10Hz | +(1% + 3) | ||
| 999.9kHz | 10Hz | +(1% + 3) | ||
| 9.999MHz | 1kHz | +(1% + 3) | ||
| Duty Ratio | Range | Resolution | Accuracy | |
| 0.1 ? 99.9% | 0.10% | +3% | ||
| hFe | Display reads hFe approximation(0 ~ 1000) ; Ibo ~ 10uA Vce ~ 2.8V | |||
| Additional functionalities | Diode, continuity, backlight, flashlight, NCV, low battery indication, auto power off, data hold | |||
| Sampling time | About 3 times/sec | |||
| Display | 6000 counts backlit LCD | |||
| Fuse | uA, mA Gear fuse FF630mA/250V; A Gear Fuse :FF20A/250V | |||
| Operating temperature | 18C ~ 28C | |||
| Storage temperature | -10C ~ 50C | |||
| Power | 1 x 9V 6F22 | |||
| Size & weight | 190 x 90 x 50 mm, approx. 380g(incl. battery) | |||
| Standard Accessories | Main unit, test leads, temperature probe, user manual, battery | |||
