Description
Technical Data
- Accuracy: ??3??m for micrometer head feed
- Graduation: 0.01mm or .001????
- Flatness of reference face: 1.3????m for 63.5mm width base, 2????m for 101.6mm width base
- Flatness of measuring rod face: 0.3????m
- Parallelism between reference face and measuring rod face:
- (4+L/50)????m, L=Max. measuring length (mm)
- Measuring rod diameter: 4mm
*with carbide-tipped measuring rod
Additional Information
| EAN | 4946368016252 |
|---|---|
| Weight (in lbs) | 1 |
| Manufacturer | Mitutoyo |
| Gage Type | Micrometer |
| Measuring range | 0-25mm |
| Resolution | 0.01mm |
| Accuracy | +/-0.003mm |
| Remarks | 101.6mm x 16mm Base |
