KYORITSU - DIGITAL MULTIMETER - 1009

KYORITSU – DIGITAL MULTIMETER – 1009

Original price was: ₹9,185.00.Current price is: ₹6,804.00.

Display : 4000 counts.

Auto range and manual range selector provided (with range hold feature).

Resistance range provides audible continuity test.

Automatically turns power off in about 30 minutes to conserve battery life.

Direct current measurement up to 10A AC and DC.

With Holster.



DCACV ?DCACA ?Resistance ?Continuitybuzzer ?Diode ?Capacitance

Frequency ?DUTY ?DATAHOLD ?Relative ?AutoPowerOff

Order on WhatsApp

Pay Online

Low Prices

Price match guarantee

Guaranteed Fitment.

Always the correct part

In-House Experts.

We know our products

Easy Returns.

Quick & Hassle Free

Categories: ,

Description

DC V 400mV/4/40/400/600V (Input Impedance 10M?) ?0.6%rdg?4dgt (400mV/4/40/400V) ?1.0%rdg?4dgt (600V)
AC V 400mV/4/40/400/600V (Input Impedance 10M?) ?1.6%rdg?4dgt (20 – 400mV) ?1.3%rdg?4dgt (4/40V) ?1.6%rdg?4dgt (400/600V)
DC A 400/4000?A/40/400mA/4/10A ?2.0%rdg?4dgt
(400/4000?A)?1.0%rdg?4dgt
(40/400mA) ?1.6%rdg?4dgt (4/10A)
AC A 400/4000?A/40/400mA/4/10A ?2.6%rdg?4dgt
(400/4000?A) ?2.0%rdg?4dgt (40/400mA/4/10A)
? 400?/4/40/400k?/4/40M? ?1.0%rdg?4dgt (400?/4/40/400k?/4M?) ?2.0%rdg?4dgt (40M?)
Continuity buzzer 400? (Buzzer sounds below 100?)
Diode test 1.5V Release Voltage:Approx. 0.4mA Test Current
Capacitance 40/400nF/4/40/100?F
Frequency 5.12/51.2/512Hz/5.12/51.2/512kHz/5.12/10MHz
DUTY 0.1 – 99.9% (Pulse width/Pulse period) ?2.5%?5dgt
Applicable standards IEC 61010-1 CAT III 300V
IEC 61010-2-031
IEC 61326
Power source R6 (1.5V) ? 2
Dimensions 161(L) ? 82(W) ? 50(D)mm
Weight Approx. 280g
Included Accessories 7066A (Test leads)
8919 (Ceramic fuse [10A/600V])? 1
8923 (Fuse [0.5A/600V])? 1
R6? 2
Instruction Manual
Optional Accessories 7234 (Crocodile clip test lead)
9095 (Carrying case)
